Release Selmo Studio 2024.4

DIE SELMO STUDIO VERSION 2024.4 IST RELEASED!

Sie enthält eine Reihe von Optimierungen und neue Features.

• Selmo Studio: Possibility to overwrite already existing assemblies in the repository.
• Selmo Studio: Internal optimization for automation peer exceptions.
• Selmo Studio: Fixed bug where the PDF export is canceled with an exception
• Selmo Studio: Enhanced project layout optimization to zone lamp indexes.
• Selmo Studio: Added possibility to pack all project outputs (generated HMI and PLC code) and used assemblies of a project into a ZIP file. This function can be found via the context menu in the project explorer.
• Selmo Studio: Added possibility to get a 30-days trial license when starting selmo studio without an installed license.
• Selmo Studio: Added possibility to export and import entire hardware zones.
• Selmo Studio: Added possibility to copy and paste entire hardware zones
• Selmo Studio System Layer: Fixed bug where some parameters are not cloned to inverted zone.
• Selmo Studio System Layer: Fixed a bug where the step name and group name are only editable with text input from keyboard and not with mouse click.
• Selmo Studio System Layer: Added the possibility to select parameters in zone or step properties from neighboring sequences as well.
• Selmo Studio System Layer: Added possibility to filter zones with multiple search terms; the separator is ';'.
• Selmo Studio System Layer: Added operands filter to the system layer, which means that only zones will be shown that have at least one operand in all selected steps.
• Selmo Studio Parameter List Layer: Fixed bug where the window parameter columns are not shown.
• Selmo Studio Parameter Layer: Fixed bug where the section is not trimmed after editing ended.
• Selmo Studio Parameter Layer: Fixed bug where parameter groups are not expanded when the search is started.
• Selmo Studio Parameter Layer: Fixed bug where copied parameters from different layer also add '_1' text.
• Selmo Studio Parameter Layer: Added possibility to set historic data
• Selmo Studio Parameter Layer: Added possibility to declare more than one section per parameter to show one parameter in more sections. Section separators are ';' and '|'.
• Selmo Studio Parameter Layer: Added possibility to declare a parameter as hardware input or output
• Selmo Studio Logic Layer: Now it will be prevented, that cross sequence steps can be copied without their corresponding twin step.
• Selmo Studio Logic Layer: Fixed bug where the icon for the second belonging cross sequence step is not showed
• Selmo Studio Logic Layer: Fixed bug where cross sequence steps are not able to copy
• Selmo Studio Logic Layer: Fixed bug where connect feature is not working when more than one outgoing link are present
• Selmo Studio Logic Layer: Fixed bug where auto moving shapes after insertion of new steps is not working inside a jump or repeater connection
• Selmo Studio Logic Layer: Fixed a bug where the loop connector was incorrectly reconnected to a newly added step when auto-connect is enabled.
• Selmo Studio Logic Layer: Fixed a bug where the comment shape could not be copied.
• Selmo Studio Logic Layer: Fixed a bug where text in clipboard is pasted as a new step when any other step is in edit mode.
• Selmo Studio Logic Layer: Fixed a bug where a shape is not restored, when a step has no correlation to the logic layer.
• Selmo Studio Logic Layer: Added ribbon button to create a connection automatically between two selected steps
• Selmo Studio Language Layer: Added possibility to paste cells from clipboard.
• Selmo Studio CMZ Layer: Fixed bug where CMZ with defined parameters is not able to copy.
• Selmo Studio Assembly Layer: Added possibility to select parameters at the assemblies from hardware zone or plant level
• Selmo HMI: Fixed bug with long HMI texts at parameters.
• Selmo HMI: Fixed bug where the feedback of the manual button is not correct at inverted zones
• Selmo HMI: Fixed a bug where the warning symbol is not shown when step property 'show indication' is set.
• Selmo HMI: Fixed a bug where the process set value snapshots are not working properly with an OPC UA connection.
• Selmo HMI: Fixed a bug where the plant parameters are not scrollable.
• Selmo HMI: Fixed a bug where a second instance of a generated HMI generates database errors.
• Selmo HMI: Added the possibility to store historical data only when the value exceeds a configured threshold.
• Selmo HMI: Added the possibility to change the manual button mode from push button to switch with the pin button besides the manual button.
• Selmo HMI: Added historic data chart view.
• PLC code generation: Improved error handling implemented when a repeater is connected to subsequent steps.
• PLC code generation: Fixed bug where the output group could not be declared as a hardware output
• PLC code generation: Fixed bug where the input and output variable are not matching the analog setpoint parameter data type in zone mode \
• PLC code generation: Fixed bug where OPC UA attribute is missing at sequence assembly variable declarations
• PLC code generation: Added datatype conversion to output distribution and parameter list assigns.

• PLC code generation: Added attribute 'ISREFERENCE' to externals io's of assemblies.

Das Update wird automatisch beim Selmo Studio Start angezeigt.
